Internal Categories

Categories inside categories

The Idea: Categories All the Way Down

A category has objects and morphisms.

What if the "collection of objects" and "collection of morphisms" are themselves categories?

This leads to double categories — a richer categorical structure with two dimensions of composition.

Internal Categories: The General Pattern

An internal category in a category \mathcal{A} (with pullbacks) consists of:

• Object of objects: C_0 \in \mathcal{A}

• Object of morphisms: C_1 \in \mathcal{A}

• Source and target: s, t : C_1 \to C_0

• Identity: e : C_0 \to C_1

• Composition: c : C_1 \times_{C_0} C_1 \to C_1

The Pullback for Composition

The composition uses the pullback C_1 \times_{C_0} C_1:

C₁ ×_{C₀} C₁ ──→ C₁
      │           │
      ↓           ↓ s
     C₁ ────────→ C₀
            t

This captures composable pairs: morphisms where the target of one equals the source of the other.

Category Axioms Internalized

The internal category must satisfy:

• Associativity: c \circ (c \times 1) = c \circ (1 \times c)

• Left identity: c \circ (e \times 1) = 1

• Right identity: c \circ (1 \times e) = 1

These are the usual category axioms, expressed as commutative diagrams in \mathcal{A}.

Category Internal to Set

Let \mathcal{A} = \mathbf{Set}:

• C_0 is a set of objects

• C_1 is a set of morphisms

• s, t, e, c are functions

This is exactly the definition of a small category!

Every small category is a category internal to \mathbf{Set}.

Double Categories

Two dimensions of composition

Category Internal to Cat

Now let \mathcal{A} = \mathbf{Cat}:

• C_0 is a category — its objects are our objects, its morphisms are vertical morphisms

• C_1 is a category — its objects are horizontal morphisms, its morphisms are 2-cells

• s, t, e, c are functors

This gives us a double category!

The Four Components

A double category \mathbb{D} has four kinds of data:

1. Objects: the objects of C_0

2. Vertical morphisms: the morphisms of C_0

3. Horizontal morphisms: the objects of C_1

4. 2-cells (squares): the morphisms of C_1

Visualizing a 2-Cell

A 2-cell \alpha is a square with four boundaries:

      f
  A ────→ B
  │   α   │
u │       │ v
  ↓       ↓
  C ────→ D
      g

• Top/bottom: horizontal morphisms f, g

• Left/right: vertical morphisms u, v

Notation for 2-Cells

We write a 2-cell as:

\alpha : \begin{pmatrix} f \\ u \quad v \\ g \end{pmatrix}

Or simply draw the square. The 2-cell \alpha "fills" the boundary.

Vertical Composition

2-cells compose vertically by stacking:

      f           f
  A ────→ B   A ────→ B
  │   α   │   │       │
  ↓       ↓   │ α∘β   │
  C ────→ D = │       │
  │   β   │   ↓       ↓
  ↓       ↓   E ────→ F
  E ────→ F

Horizontal Composition

2-cells compose horizontally by placing side by side:

      f       g           f∘g
  A ────→ B ────→ C   A ──────→ C
  │   α   │   β   │ = │  α∘β   │
  ↓       ↓       ↓   ↓        ↓
  D ────→ E ────→ F   D ──────→ F

The Interchange Law

Vertical and horizontal composition satisfy the interchange law:

(\alpha \circ_v \beta) \circ_h (\gamma \circ_v \delta) = (\alpha \circ_h \gamma) \circ_v (\beta \circ_h \delta)

This ensures the two compositions are compatible.

Examples

Squares, spans, and profunctors

Example: Squares in a Category

Given any category \mathcal{C}, form \mathbf{Sq}(\mathcal{C}):

• Objects: objects of \mathcal{C}

• Horizontal morphisms: morphisms of \mathcal{C}

• Vertical morphisms: morphisms of \mathcal{C}

• 2-cells: commutative squares in \mathcal{C}

This is the simplest double category.

Example: Spans

In a category \mathcal{C} with pullbacks, form \mathbf{Span}(\mathcal{C}):

• Objects: objects of \mathcal{C}

• Horizontal morphisms: spans A \leftarrow X \rightarrow B

• Vertical morphisms: morphisms of \mathcal{C}

• 2-cells: morphisms of spans

What is a Span?

A span from A to B is a diagram:

      X
     ↙ ↘
    A   B

Spans compose using pullbacks:

      X ×_B Y
       ↙   ↘
      X     Y
     ↙ ↘   ↙ ↘
    A   B   C

Example: Profunctors

The double category \mathbf{Prof}:

• Objects: small categories

• Horizontal morphisms: profunctors P : \mathcal{A}^{op} \times \mathcal{B} \to \mathbf{Set}

• Vertical morphisms: functors

• 2-cells: natural transformations

Profunctors generalize functors and relations.

Why Double Categories?

Beyond 2-categories

Why Double Categories?

2-categories have only one kind of 1-morphism.

Double categories have two: horizontal and vertical.

This models situations with two different "directions":

• Spaces vs. paths

• Types vs. terms

• Syntax vs. semantics

Monads and Bimodules

Categories as monads in Span

Monads in 2-Categories

Recall: a monad in a 2-category on object A is:

• An endomorphism T : A \to A

• A unit \eta : 1_A \Rightarrow T

• A multiplication \mu : T \circ T \Rightarrow T

Satisfying associativity and unit laws.

Monads in Double Categories

In a double category, we can define:

Horizontal monads: monads using horizontal morphisms

• T : A \to A (horizontal)

• \eta, \mu are 2-cells

The vertical morphisms give us monad morphisms.

The Key Insight: Categories as Monads

Consider \mathbf{Span}(\mathbf{Set}):

A monad here consists of:

• An object C_0 (a set)

• A span C_0 \leftarrow C_1 \rightarrow C_0

• Unit and multiplication satisfying monad laws

Categories ARE Monads in Span

The monad data in \mathbf{Span}(\mathbf{Set}) is exactly:

• C_0: set of objects

• C_1 \to C_0 \times C_0: morphisms with source and target

• Unit: identity morphisms

• Multiplication: composition

A small category is a monad in the double category of spans!

Why Double Categories Beat Bicategories

In a bicategory, monad morphisms are too restrictive.

They require strict commutation with the monad structure.

In a double category, vertical morphisms give lax monad morphisms.

These correspond to functors between categories!

Monad Morphisms in Span

A vertical monad morphism in \mathbf{Span}(\mathbf{Set}):

  C₀ ←── C₁ ──→ C₀
  │      │      │
  F₀     F₁     F₀
  ↓      ↓      ↓
  D₀ ←── D₁ ──→ D₀

This is exactly a functor F : \mathcal{C} \to \mathcal{D}!

Monads in Prof

A monad in \mathbf{Prof} on a category \mathcal{A}:

• A profunctor T : \mathcal{A} \to \mathcal{A}

• Unit and multiplication

Special case: on a discrete category, this gives a small category.

Monads in Prof generalize enriched categories.

Bimodules: Beyond Monads

A monad is a monoid in endomorphisms.

But what about morphisms between monads on different objects?

This leads to bimodules — the horizontal morphisms between monads.

What is a Bimodule?

Given monads S on A and T on B, an (S,T)-bimodule is:

• A horizontal morphism M : A \to B

• Left action: \lambda : S \circ M \to M

• Right action: \rho : M \circ T \to M

Satisfying associativity and unit laws.

Bimodule Axioms

The actions must be compatible:

S ∘ M ∘ T ──→ M ∘ T ──→ M
    │                   ‖
    ↓                   ‖
  S ∘ M ─────────────→ M

Both paths give the same result.

Bimodules in Span

In \mathbf{Span}(\mathbf{Set}):

• Monads = categories

• Bimodules = ???

An (\mathcal{C}, \mathcal{D})-bimodule is a span with compatible actions.

Bimodules ARE Profunctors!

A bimodule M : \mathcal{C} \to \mathcal{D} in Span is:

• A set M with maps to C_0 and D_0

• Left \mathcal{C}-action: precomposition with morphisms

• Right \mathcal{D}-action: postcomposition with morphisms

This is exactly a profunctor \mathcal{C}^{op} \times \mathcal{D} \to \mathbf{Set}!

The Profunctor Perspective

A profunctor P : \mathcal{C} \to \mathcal{D} assigns:

• To each pair (c, d), a set P(c, d)

• Left action: f : c' \to c gives P(c,d) \to P(c',d)

• Right action: g : d \to d' gives P(c,d) \to P(c,d')

Profunctors generalize the Hom functor!

The Hom Profunctor

Every category has a canonical profunctor:

\mathrm{Hom} : \mathcal{C}^{op} \times \mathcal{C} \to \mathbf{Set}

This is the identity bimodule for \mathcal{C}.

Composition of profunctors uses coends — like matrix multiplication.

The Double Category of Monads

Given \mathbb{D}, form \mathbf{Mnd}(\mathbb{D}):

• Objects: monads in \mathbb{D}

• Vertical morphisms: monad morphisms

• Horizontal morphisms: bimodules

• 2-cells: bimodule morphisms

This is itself a double category!

The Equivalence

For \mathbf{Span}(\mathbf{Set}):

\mathbf{Mnd}(\mathbf{Span}) \simeq \mathbf{Prof}

• Monads \leftrightarrow Categories

• Monad morphisms \leftrightarrow Functors

• Bimodules \leftrightarrow Profunctors

Prof arises naturally from Span!

Why Bimodules Matter

Functors are "strict" — they preserve structure exactly.

Profunctors/bimodules allow heteromorphisms:

• Elements of P(c,d) are "generalized morphisms" from c to d

• No requirement that c and d live in the same category

Bimodules are the natural "1-cells" between monads.

Example: Polynomial Monads

The double category of polynomial functors:

• Objects: sets

• Horizontal morphisms: P(X) = \sum_{a:A} X^{B_a}

Monads here include:

• Lists: L(X) = 1 + X \cdot L(X)

• Binary trees: T(X) = X + T(X)^2

The Eilenberg-Moore Construction

Given a horizontal monad T in \mathbb{D}:

We can form \mathbf{EM}(T):

• Objects: T-algebras

• Morphisms: algebra morphisms

This generalizes the usual Eilenberg-Moore category.

Double Functors

A double functor F : \mathbb{D} \to \mathbb{E} preserves:

• Objects \mapsto Objects

• Horizontal morphisms \mapsto Horizontal morphisms

• Vertical morphisms \mapsto Vertical morphisms

• 2-cells \mapsto 2-cells

Plus: composition and identities in both directions.

Summary

• Internal categories: categories defined inside another category

• Category in Set: small category

• Category in Cat: double category

• Four components: objects, horizontal/vertical morphisms, 2-cells

• Key examples: \mathbf{Sq}(\mathcal{C}), \mathbf{Span}, \mathbf{Prof}

The Unifying Perspective

Double categories reveal hidden structure:

• Categories = monads in Span

• Functors = monad morphisms

• Profunctors = bimodules between monads

The double category \mathbf{Prof} arises as \mathbf{Mnd}(\mathbf{Span})!
