Motivation

Why machine-checked cryptography?

The Challenge of Cryptographic Proofs

Security proofs in cryptography are:

• Complex: many interacting components and subtle conditions

• Error-prone: even published proofs contain mistakes

• Hard to verify: peer review catches some errors, but not all

Example: SSProve found an error in a published KEM-DEM composition proof!

Why Machine-Checked Proofs?

Paper proofs rely on human verification, which is fallible.

Machine-checked proofs provide:

• High assurance: the computer verifies every step

• Reproducibility: anyone can re-run the verification

• Precision: no ambiguity in definitions or reasoning

Goal: Bridge informal cryptographic reasoning and formal verification.

Game-Based Security Proofs

Security is defined relative to an adversary playing a game:

1. The adversary interacts with the system through oracles

2. The adversary tries to win (e.g., distinguish real from random)

3. Advantage = probability of winning minus \frac{1}{2}

A scheme is secure if no efficient adversary has non-negligible advantage.

Example: IND-CPA Security

The indistinguishability under chosen-plaintext attack game:

1. Adversary chooses two messages m_0, m_1

2. Challenger encrypts m_b for random bit b

3. Adversary guesses which message was encrypted

Advantage = \left| P[\mathrm{correct}] - \frac{1}{2} \right|

The Game Hopping Technique

Proofs work by transforming one game into another:

Game₀ → Game₁ → Game₂ → ... → Gameₙ

Each step:

• Changes the game slightly

• Bounds the advantage difference

Sum the bounds to get overall security.

Packages

Modular composition of cryptographic systems

What is a Package?

A package bundles together:

• Code: procedure implementations

• State: private memory locations

• Export interface: procedures provided to others

• Import interface: procedures called from others

Packages are the fundamental building block of SSProve.

Package Example

An encryption package might look like:

Package Enc:
  State: key k
  Exports: encrypt(m), decrypt(c)
  Imports: random()

The package provides encryption/decryption and uses an external random oracle.

Sequential Composition

Packages can be linked sequentially: P \circ Q

• P's imports are satisfied by Q's exports

• Result exports P's procedures

• Result imports Q's remaining imports

Like function composition, but for modules.

Sequential Composition: Example

   Enc           KeyGen
┌────────┐    ┌────────┐
│encrypt │───→│derive  │
│decrypt │    │        │
└────────┘    └────────┘

\mathsf{Enc} \circ \mathsf{KeyGen}: encryption linked to key derivation.

Parallel Composition

Packages can run side by side: P \| Q

• Both packages run independently

• Combined exports = union of exports

• Combined imports = union of imports

Enables building complex systems from components.

Parallel Composition: Example

┌────────────────────┐
│  ┌─────┐  ┌─────┐  │
│  │ Enc │  │ MAC │  │
│  └─────┘  └─────┘  │
└────────────────────┘

\mathsf{Enc} \| \mathsf{MAC}: encryption and authentication in parallel.

Algebraic Laws: Associativity

Sequential composition is associative:

(P \circ Q) \circ R = P \circ (Q \circ R)

Parallel composition is associative:

(P \| Q) \| R = P \| (Q \| R)

Algebraic Laws: Identity and Commutativity

Identity packages exist:

\mathsf{ID} \circ P = P = P \circ \mathsf{ID}

Parallel composition is commutative:

P \| Q = Q \| P

The Interchange Law

The key structural law:

(P_1 \circ Q_1) \| (P_2 \circ Q_2) = (P_1 \| P_2) \circ (Q_1 \| Q_2)

Sequencing and parallelism interact predictably.

This enables modular reasoning about complex compositions.

State Separation

State separation is the key insight:

• Packages maintain isolated state

• They cannot access each other's memory

• This isolation enables modular proofs

If packages share state, reasoning becomes much harder.

Validity Conditions

For composition to be valid:

• Interface signatures must match

• State locations must be compatible

• No conflicts in procedure names

SSProve proves algebraic laws hold when validity is satisfied.

Proving Security

Games and relational logic

Security Games as Packages

A security game is just a package with specific structure:

• Exports an interface for the adversary

• Internally composes the scheme being analyzed

• Advantage = success difference between two games

Example: Real game (actual encryption) vs Ideal game (random values).

Relational Program Logic

Need to prove two programs behave equivalently:

\{P\}\ c_1 \sim c_2\ \{Q\}

Meaning: If precondition P holds, then after running both programs, postcondition Q holds.

This is probabilistic relational Hoare logic.

Key Rules: Reflexivity and Sampling

Reflexivity: Any code is equivalent to itself.

\{P\}\ c \sim c\ \{P\}

Uniform sampling: Fresh random values are indistinguishable.

x \leftarrow \mathsf{random}() \sim y \leftarrow \mathsf{random}()

Key Rules: Dead Code

Dead code elimination: Unused computations can be removed.

x ← compute();    ≈    skip
(x never used)

This is essential for simplifying game transformations.

Key Rules: Conditionals and Loops

Conditional coupling: Related if-then-else statements:

\mathsf{if}\ b_1\ \mathsf{then}\ c_1\ \mathsf{else}\ d_1 \sim \mathsf{if}\ b_2\ \mathsf{then}\ c_2\ \mathsf{else}\ d_2

Loop invariants: Reason about loops by finding invariants.

The Two-Level Proof Architecture

High level: Algebraic manipulation of packages

• Use composition laws to restructure systems

• Modular and reusable proofs

Low level: Relational program logic

• Prove code equivalences

• Handle implementation details

SSProve connects both levels.

Categorical Foundations

Relative monads for cryptography

What is a Monad?

A monad captures computational effects (state, randomness, exceptions):

• An endofunctor T : \mathcal{C} \to \mathcal{C}

• A unit: \eta : \mathrm{Id} \Rightarrow T

• A multiplication: \mu : T \circ T \Rightarrow T

Satisfying associativity and unit laws.

The Problem with Standard Monads

Standard monads are endofunctors — same category in and out.

But cryptographic code involves:

• Finite types (interfaces, signatures)

• Distributions over arbitrary types

• State indexed by memory locations

These live in different categories!

Relative Monads

A relative monad generalizes monads across categories:

Given J : \mathcal{D} \to \mathcal{C}, a relative monad is:

• T : \mathcal{D} \to \mathcal{C} (not necessarily an endofunctor!)

• Unit: \eta : J \Rightarrow T

• Bind: extends J(A) \to T(B) to T(A) \to T(B)

When J = \mathrm{Id}, we recover standard monads.

Relative Monads for Cryptography

In SSProve, relative monads model:

\mathsf{Code} : \mathsf{Interface} \to \mathsf{Distributions}

• Input: Interface category (import/export signatures)

• Output: Distributions over program outcomes

• Effects: State access, random sampling, oracle calls

The relative structure handles the category mismatch.

Example: The Free Monad

Cryptographic code is modeled as a free monad over operations:

Code A = Pure A
       | Sample (Dist A) (A → Code B)
       | Get Loc (Val → Code A)
       | Put Loc Val (Code A)
       | Call Op Args (Ret → Code A)

External calls (Call) are algebraic operations — handled by linking.

Order-Enriched Structure

SSProve uses order-enriched relative monads:

• Morphisms carry a partial order \leq

• f \leq g means "f refines g" or "f is more defined"

• Enables reasoning: "this implementation is at least as good"

Lax morphisms preserve this order structure.

Why Order Enrichment?

Order enrichment enables:

• Approximation: relate partial implementations

• Refinement: prove one game is "better" than another

• Probability bounds: P[A] \leq P[B] + \epsilon

The relational program logic builds on this foundation.

From Relative Monads to Packages

The categorical structure ensures soundness:

• Sequential composition = Kleisli composition in the relative monad

• Monad laws give associativity and identity for packages

• Algebraic effects (imports) handled via the relative structure

The math guarantees the package laws hold!

The Semantic Picture

┌─────────────┐     T      ┌──────────────┐
│  Interface  │ ─────────→ │ Distributions │
│  Category   │            │   Category    │
└─────────────┘            └──────────────┘
       ↑                          ↑
       │ J                        │
       │                          │
┌─────────────┐                   │
│ Finite Types│ ──────────────────┘
└─────────────┘

Relative monads bridge different categorical worlds.

Case Studies

PRF, ElGamal, and KEM-DEM

Case Study: PRF Security

A Pseudorandom Function (PRF) is indistinguishable from random:

• Game 0: Adversary queries actual PRF

• Game 1: Adversary queries truly random function

Advantage bounded by distinguishing these games.

PRF: The Proof Structure

┌───────────┐        ┌───────────┐
│ Real Game │   ≈    │Ideal Game │
│  ┌─────┐  │        │  ┌─────┐  │
│  │ PRF │  │        │  │Rand │  │
│  └─────┘  │        │  └─────┘  │
└───────────┘        └───────────┘

Security follows from the PRF assumption.

Case Study: ElGamal Encryption

ElGamal is a classic public-key encryption scheme.

Security reduces to Decisional Diffie-Hellman (DDH):

• Given (g, g^a, g^b, Z), is Z = g^{ab} or random?

DDH hardness implies ElGamal security.

ElGamal: Game Hops

Real Encryption → DDH Challenge → Random Values

Each hop is justified by:

• Algebraic package transformations

• Relational program logic proofs

SSProve formally verifies this reduction.

Case Study: KEM-DEM Composition

Hybrid encryption:

• KEM: Key Encapsulation Mechanism (public-key)

• DEM: Data Encapsulation Mechanism (symmetric-key)

Security should follow from component security...

The KEM-DEM Error

The original paper proof had a subtle error!

• Discovered during SSProve formalization

• Required fixing the proof structure

• Shows value of machine-checked proofs

Lesson: Even peer-reviewed proofs can be wrong.

Formalizing in Coq

SSProve is fully implemented in Coq (now Rocq):

• Algebraic laws proven as theorems

• Program logic rules proven sound

• Case studies machine-checked

Install: opam install rocq-ssprove

What SSProve Enables

• Catch errors in published proofs

• Modular proofs reusable across protocols

• Connect intuition to formal guarantees

• Verify real protocols: TLS 1.3, MLS key schedules

Summary: The SSProve Approach

1. Model systems as packages with clean interfaces

2. Compose with algebraic operations

3. State separation enables modularity

4. Two-level proofs: algebra + program logic

5. Machine-checked in Coq

The Big Idea

SSProve makes formal cryptographic verification practical:

Instead of trusting paper proofs, we can verify them.

"Trust, but verify" — now with mathematical certainty.
